<h2 style=”text-align: center;”>Explore Our Ignition and Heating Systems</h2>
<p style=”text-align: center;”>Ignition and Heating Systems are our core business.Kelinco is a professional manufacturer and supplier of gas ignition and heating components, including spark plugs, hot surface ignitors, infrared ceramic plaques, thermocouples, pilot lights, piezo igniters and pulse igniters. Select your product below to view details and specifications.</p>
Spark Plug
Spark Plug
①Ignition cable for gas stoves;
②Ceramic: 95% alumina;
③Cable: Teflon / silicone rubber;
④Electrode: Stainless steel, 0Cr25Al5, Kanthal.
Hot Surface Ignitor
Hot Surface Ignitor
①Material: Silicon nitride
②Max. working temperature: 1200℃
③Voltage: AC 110-240V; DC 12-36V
④Power: 100W-1000W
⑤Service life: 100,000 on/off cycles
Infrared Ceramic Plaque
Infrared Ceramic Plaque
①Material: Cordierite
②Burning temperature: up to 1200℃
③Size: up to 180x180mm
④For heaters, burners and barbecues
Thermocouple
Thermocouple
①Thermocouple sensor for flame-out protection;
②Material: copper;
③No-load voltage at 600℃: ≥25mV;
④Residual voltage: ≤1.5mV;
⑤Resistance tolerance: ±3mΩ;
Pilot Light
Pilot Light
①For gas ignition systems;
②Components: electrode, thermocouple, bracket, nozzle
③Gas: NG / LPG
Piezo Igniter For Valve
Piezo Igniter For Valve
①Color: black and gray
②Service life: ≥20,000 cycles
③Output voltage: >13kV
④Spark gap: ≥3mm
Non-Push Button Pulse Igniter
Non-Push Button Pulse Igniter
①For gas oven ignition;
②Working voltage: AC 220V / 110V, DC 1.5V;
③Output voltage: >18kV;
④Material: PA66;
⑤Outlets: 2 / 4 / 6 / 8
Piezo Ignitor For Heater
Piezo Ignitor For Heater
①For gas ignition;
②Service life: 30,000 cycles
③Output voltage: >18kV
④Outlets: 1 / 2 / 3
Push Button Pulse Igniter
Push Button Pulse Igniter
①Igniter for gas grills, BBQs and other stoves;
②Working voltage: DC 1.5V;
③Output voltage: >18kV;
④Service life: 30,000 cycles;
⑤Outlets: 1-8
Ceramic Insulator
Ceramic Insulator
①Alumina ceramic insulator;
②Material: 95% / 99% alumina;
③Voltage resistance: over 15kV;
④Temperature resistance: 1500℃
Magnet Unit
Magnet Unit
①Flame-out protection device for gas valves;
②Gas: NG / LPG;
③Connection current: ≤200mA;
④Close current: ≥40mA;
⑤Size: 8.5-17.5mm
Timer
Timer
①Mechanical timer for microwave ovens, electric pressure cookers, electric ovens, etc.;
②Time setting range: 5 / 15 / 30 / 60 / 75 / 90 / 120 / 180 min
<h2 style=”text-align: center;”>Why Choose Kelinco</h2>
Applications of Our Ignition and Heating Systems Components
Our high-quality ignition and heating systems parts are widely used across various industries. Whether you are manufacturing commercial gas fryers, industrial boilers, or residential gas fireplaces, Kelinco provides the perfect match.
Commercial Cooking: Our spark plugs and thermocouples ensure safety and efficiency in restaurant equipment.
Heating Systems: The infrared ceramic plaques are ideal for patio heaters and industrial drying processes.
Water Heaters: Reliable pulse igniters and solenoid valves for instant water heating solutions.
We understand that stability and durability are crucial. That’s why every gas valve and pilot assembly undergoes strict testing before shipment.
